Brass
We offer a comprehensive range of brass tubes, brass tube products, brass wire tubes in various specifications. All our brass tubes, brass capillary tube have high degree of precision, dimensional accuracy and excellent corrosion resistance. We manufacture brass tubes in a size ranging from 3 mm OD x .015 mm wall thickness to 50 mm OD x 2.5 mm wall thickness in the following compositions, which are readily available in stock.
| Alloy | UNS Number | Composition (%) | Density (g/cm³) | Melting Point (°C) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Applications |
|---|---|---|---|---|---|---|---|---|
| C21000 (Gilding) | C21000 | Cu 95, Zn 5 | 8.83 | 899-916 | 345-465 | 105-345 | 15-30 | Jewelry, architectural trim, medals |
| C22000 (Commercial Bronze) | C22000 | Cu 90, Zn 10 | 8.83 | 899-916 | 345-550 | 105-240 | 25-45 | Architectural applications, musical instruments |
| C23000 (Red Brass) | C23000 | Cu 84-86, Zn 14-16 | 8.53 | 885-910 | 330-420 | 90-150 | 30-40 | Plumbing accessories, pump cylinders, marine hardware |
| C24000 (Low Brass) | C24000 | Cu 80, Zn 20 | 8.53 | 899-915 | 380-550 | 105-255 | 30-45 | Fasteners, architectural trim, musical instruments |
| C26000 (Cartridge Brass) | C26000 | Cu 68.5-71.5, Zn 28.5-31.5 | 8.53 | 904-932 | 315-560 | 95-275 | 40-65 | Ammunition casings, radiator cores, architectural hardware |
| C28000 (Muntz Metal) | C28000 | Cu 60, Zn 40 | 8.47 | 899-920 | 360-540 | 90-260 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| C33000 (Low-Leaded Brass) | C33000 | Cu 65-68, Zn 32-34, Pb 0.5-1.5 | 8.45 | 899-915 | 310-480 | 80-180 | 30-50 | Plumbing fixtures, automotive components |
| C35300 (Leaded Brass) | C35300 | Cu 61.5-64.5, Zn 34.5-37.5, Pb 1.5-2.5 | 8.47 | 899-915 | 310-480 | 80-190 | 30-50 | Precision machining, valve stems, pump shafts |
| C36000 (Free-Cutting Brass) | C36000 | Cu 60-63, Zn 35.5-38.5, Pb 2.5-3.7 | 8.44 | 885-905 | 380-480 | 90-180 | 20-36 | Precision machining, screw machine parts, valve components |
| C37000 (Architectural Bronze) | C37000 | Cu 57-61, Zn 38-41, Pb 0.5-1.5 | 8.40 | 880-890 | 400-500 | 140-300 | 20-35 | Architectural applications, plumbing fixtures |
| C38500 (Architectural Bronze) | C38500 | Cu 57-60, Zn 38-41, Pb 1.5-2.5 | 8.44 | 870-890 | 370-485 | 80-240 | 15-30 | Architectural applications, plumbing fixtures |
| C46400 (Naval Brass) | C46400 | Cu 59, Zn 40, Sn 1 | 8.53 | 899-920 | 380-540 | 105-255 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| C48500 (Naval Brass) | C48500 | Cu 60, Zn 39, Sn 1 | 8.53 | 899-920 | 345-525 | 90-240 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| C68700 (Aluminum Brass) | C68700 | Cu 76-79, Zn 20-23, Al 1-1.5 | 8.53 | 900-925 | 350-550 | 100-250 | 30-45 | Marine hardware, heat exchangers, industrial applications |
| C74500 (Nickel Silver) | C74500 | Cu 65, Zn 18, Ni 17 | 8.65 | 930-1040 | 380-690 | 100-350 | 10-30 | Electrical connectors, musical instruments, architectural applications |
Our brass tubes and brass tube products are widely used in heat exchangers, refineries, power plants,
desalination plants, ship building, condensers, distillers etc.
Seamless Brass Tubes: Made by extrusion, resulting in a tube without any joints or seams. These are stronger and have better corrosion resistance.
Welded Brass Tubes: Made by welding together strips of brass. They are generally cheaper but can have lower strength and corrosion resistance compared to seamless tubes.
| EN Number | Alloy Designation | Composition (%) | Density (g/cm³) | Melting Point (°C) | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Applications |
|---|---|---|---|---|---|---|---|---|
| EN CW502L | CuZn10 | Cu 90, Zn 10 | 8.83 | 899-916 | 345-465 | 105-345 | 15-30 | Jewelry, architectural trim, medals |
| EN CW503L | CuZn15 | Cu 85, Zn 15 | 8.53 | 885-910 | 330-420 | 90-150 | 30-40 | Plumbing accessories, pump cylinders, marine hardware |
| EN CW504L | CuZn20 | Cu 80, Zn 20 | 8.53 | 899-915 | 380-550 | 105-255 | 30-45 | Fasteners, architectural trim, musical instruments |
| EN CW505L | CuZn30 | Cu 70, Zn 30 | 8.47 | 904-932 | 315-560 | 95-275 | 40-65 | Ammunition casings, radiator cores, architectural hardware |
| EN CW506L | CuZn33 | Cu 67, Zn 33 | 8.47 | 899-920 | 360-540 | 90-260 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| EN CW507L | CuZn37 | Cu 63, Zn 37 | 8.44 | 885-905 | 310-480 | 80-180 | 30-50 | Precision machining, valve stems, pump shafts |
| EN CW508L | CuZn40 | Cu 60, Zn 40 | 8.44 | 870-890 | 370-485 | 80-240 | 15-30 | Architectural applications, plumbing fixtures |
| EN CW509L | CuZn42 | Cu 58, Zn 42 | 8.40 | 870-890 | 350-540 | 100-250 | 30-45 | Architectural applications, plumbing fixtures |
| EN CW510L | CuZn36Pb2As | Cu 60, Zn 36, Pb 2, As 0.1 | 8.47 | 885-905 | 310-480 | 80-180 | 30-50 | Precision machining, screw machine parts, valve components |
| EN CW511L | CuZn36Pb3 | Cu 60, Zn 36, Pb 3 | 8.47 | 870-890 | 380-480 | 90-180 | 20-36 | Precision machining, valve stems, pump shafts |
| EN CW612N | CuZn39Pb2 | Cu 59, Zn 39, Pb 2 | 8.53 | 899-920 | 380-540 | 105-255 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| EN CW614N | CuZn39Pb3 | Cu 59, Zn 39, Pb 3 | 8.53 | 899-920 | 345-525 | 90-240 | 30-55 | Marine hardware, condenser tubes, architectural applications |
| EN CW721R | CuZn20Al2As | Cu 76-79, Zn 20-23, Al 2-3, As 0.1 | 8.53 | 900-925 | 350-550 | 100-250 | 30-45 | Marine hardware, heat exchangers, industrial applications |
| EN CW724R | CuZn33Pb1.5Ni | Cu 57-60, Zn 38-41, Pb 1.5-2.5, Ni 0.3 | 8.65 | 930-1040 | 380-690 | 100-350 | 10-30 | Electrical connectors, musical instruments, architectural applications |
